Ford Escape: Climate Control System - General Information / Removal and Installation - Air Conditioning (A/C) Compressor Inlet Line - 1.5L EcoBoost (132kW/180PS) – I3 (Y1)
Removal
NOTICE:
During the removal or installation of components, cap, tape
or otherwise appropriately protect all openings and tubes/fittings to
prevent the ingress of dirt or other contamination. Remove caps, tape
and other protective materials prior to installation.
NOTE:
Removal steps in this procedure may contain installation details.
-
Recover the refrigerant. Refer to the appropriate Recovery procedure in Group 412.
-
Remove the A/C compressor inlet line nut and disconnect the fitting.
-
Make sure to cover any open ports to prevent debris from entering the system.
Torque:
159 lb.in (18 Nm)
-
-
Remove the A/C line bracket retainer.
-
Remove the A/C compressor inlet line nut, disconnect the fitting and remove the A/C compressor inlet line.
-
Make sure to cover any open ports to prevent debris from entering the system.
Torque:
Bracket retainer:
89 lb.in (10 Nm)
Compressor inlet line nut:
159 lb.in (18 Nm)
Installation
-
To install, reverse the removal procedure.
-
NOTICE:
Only use the specified material to lubricate the seals.
Install and lubricate new O-ring seals. Refer to the appropriate Specifications in Group 412.
-
Lubricate the refrigerant system with the correct amount
of clean PAG oil. Refer to the appropriate Refrigerant Oil Adding
procedure in Group 412.
Removal
NOTICE:
If installing a new A/C compressor due to an internal failure of the
old unit, carry out the following procedures to remove contamination
from the A/C system...
Removal
NOTICE:
During the removal or installation of components, cap, tape
or otherwise appropriately protect all openings and tubes/fittings to
prevent the ingress of dirt or other contamination...
