Ford Escape: Fuel Charging and Controls - Turbocharger - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / Removal and Installation - Turbocharger Oil Return Tube

Materials

Name Specification
Motorcraft® Metal Brake Parts Cleaner
PM-4-A, PM-4-B, APM-4-C
-


Removal

  1. NOTICE: The turbocharger compressor vanes can be damaged by even the smallest particles. When removing any turbocharger or engine air intake system component, ensure that no debris enters the system. Failure to do so may result in damage to the turbocharger.

    NOTICE: Special attention needs to be given to the sealing ports for the oil feed, the oil drain, and the coolant lines, on turbocharged engines. The sealing ports must be totally clean and free from O-ring residue, have no damage to the sealing surface and the lines to ensure that there are no leaks or repeat repairs.

LHD FWD/RHD FWD

  1. Remove the catalytic converter.
    Refer to: Catalytic Converter (309-00A Exhaust System - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Removal and Installation).
  1. Remove the bolts and the nut, then remove the bracket.

LHD AWD/RHD AWD

  1. Remove the power transfer unit.
    Refer to: Power Transfer Unit - Vehicles With: Power Transfer Unit Oil-to-Coolant Cooler (307-07B Power Transfer Unit - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Removal).
    Refer to: Power Transfer Unit - Vehicles Without: Power Transfer Unit Oil-to-Coolant Cooler (307-07B Power Transfer Unit - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Removal).

All Vehicles

  1. Remove the bolts, then remove and discard the oil return tube.

Installation

All Vehicles

  1. NOTE: Make sure that new O-ring seals are installed.

    Install the new O-ring seals, if not already installed, then lubricate them with clean engine oil.
    Refer to: Specifications (303-01A Engine - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Specifications).
  1. NOTE: The oil return tube must be fully seated prior to fastener rundown.

    • Carefully use a nylon brush to remove the old O-ring residue, use brake cleaner to rinse the O-ring residue out of the turbocharger tube O-ring bore. Inspect the area for deep scratches and gouges. Install new components if needed.
    1. Install the oil return tube, then install and tighten the bolts.
      Material: Motorcraft® Metal Brake Parts Cleaner / PM-4-A, PM-4-B, APM-4-C
      Torque: 97 lb.in (11 Nm)

LHD AWD/RHD AWD

  1. Install the power transfer unit.
    Refer to: Power Transfer Unit - Vehicles With: Power Transfer Unit Oil-to-Coolant Cooler (307-07B Power Transfer Unit - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Installation).
    Refer to: Power Transfer Unit - Vehicles Without: Power Transfer Unit Oil-to-Coolant Cooler (307-07B Power Transfer Unit - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Installation).

LHD FWD/RHD FWD

  1. Install the bracket, then install and tighten the bolts and the nut.
    Torque: 35 lb.ft (48 Nm)
  1. Install the catalytic converter.
    Refer to: Catalytic Converter (309-00A Exhaust System - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Removal and Installation).

All Vehicles

  1. Check and top off the engine oil as needed.
    Refer to: Specifications (303-01A Engine - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Specifications).
