Ford Escape: Instrumentation, Message Center and Warning Chimes / Removal and Installation - Instrument Panel Cluster (IPC) Lens

Removal

Remove the IPC .
Refer to: Instrument Panel Cluster (IPC) (413-01 Instrumentation, Message Center and Warning Chimes, Removal and Installation).

1. Remove the screws.
1. Release the clips and remove the IPC lens.

Installation

To install, reverse the removal procedure.
