System Operation
System Diagram
Item
Description
1
PCM
2
Starter Relay
3
Starter Motor
4
BCM
5
Brake Pedal Position Switch
6
Clutch Pedal Switch (Manual Transmission)
7
Ignition Switch
Network Message Chart
Module Network Input Messages Powertrain Control Module (PCM)
..
Removal
NOTE:
Removal steps in this procedure may contain installation details.
Remove the RH loadspace trim panel.
Refer to: Loadspace Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
Disconnect the electrical connector, separate the wiring guide, remove the bolts and the subwoofer speaker.
Torque:
62 lb.in (7 Nm)
..
