Other information:
System Operation
System Diagram
Item
Description
1
GWM
2
Ambient Air Temperature (AAT) sensor
3
PCM
4
A/C pressure transducer
5
A/C clutch relay
6
A/C compressor clutch field coil
7
HVAC Control Module
8
Air distribution door actuator
9
Temperature door actuator
10
Air inlet door actuator
11..
Tire Pressure Monitoring System – Warning Lamps
The low tire pressure warning
lamp has combined functions,
as it warns you when your tires
need air, and when the system is no longer
capable of functioning as intended.
Tire Pressure Monitoring System – Information Messages
..
