Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Driver Side Instrument Panel Speaker

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

  1. Position the speaker and grille up as an assembly.
    Use the General Equipment: Interior Trim Remover
  1. Disconnect and remove the speaker and grille as an assembly.
  1. Release the tabs and remove the speaker.

Installation

  1. To install, reverse the removal procedure.
