Ford Escape: Glass, Frames and Mechanisms / Removal and Installation - Rear Door Window Control Switch
Special Tool(s) /
General Equipment
Removal
NOTE:
LH (left-hand) side shown, RH (right-hand) side similar.
-
Remove the rear door window control switch bezel assembly.
-
Starting from the front, release the locking tabs from the rear door window control switch bezel assembly.
Use the General Equipment: Interior Trim Remover
-
Disconnect the electrical connector and remove the rear door window control switch bezel assembly.
-
NOTE:
This step is only necessary when installing a new component.
Remove the rear door window control switch from the bezel assembly.
-
Release the locking tabs from the rear door window control switch.
-
Remove the rear door window control switch from the bezel assembly.
Installation
-
To install, reverse the removal procedure.
