Ford Escape 2020-2023 Service Manual / Body and Paint / Body and Paint / Supplemental Restraint System / Description and Operation - Airbag and Seatbelt Pretensioner Supplemental Restraint System (SRS) - Component Location

Ford Escape: Supplemental Restraint System / Description and Operation - Airbag and Seatbelt Pretensioner Supplemental Restraint System (SRS) - Component Location

Item	Description
1	Driver knee airbag
2	Driver airbag
3	Passenger airbag (includes canister vent)
4	Second row passenger seat side airbag
5	LH / RH side air curtain
6	Second row driver seat side airbag
7	Driver/passenger side airbag

Item	Description
1	Clockspring
2	Driver and passenger front impact severity sensors
3	PAD indicator
4	OCSM (includes OCS sensor and gel-filled bladder)
5	Passenger front door side impact sensor
6	Passenger C-pillar side impact sensor
7	Passenger front seat position sensor
8	BECMB
9	Driver C-pillar side impact sensor
10	Driver seat position sensor
11	RCM
12	Driver front door side impact sensor

Item	Description
1	Driver seatbelt buckle (includes buckle sensor)
2	Front passenger seatbelt buckle (includes buckle sensor and Belt Tension Sensor (BTS))
3	Front passenger seatbelt retractor (includes retractor pretensioner, anchor pretensioner and adaptive load limiter
4	Passenger side rear outer seatbelt retractor (includes retractor pretensioner)
5	Passenger side rear outer seatbelt buckle (includes seatbelt buckle switch)
6	Center rear seatbelt buckle (includes seatbelt buckle switch)
7	Driver side rear outer seatbelt buckle (includes seatbelt buckle switch)
8	Driver side rear outer seatbelt retractor (includes retractor pretensioner)
9	Driver seatbelt retractor (includes retractor pretensioner and anchor pretensioner)

Supplemental Restraint System

Description and Operation - Airbag and Seatbelt Pretensioner Supplemental Restraint System (SRS) - Overview

Overview The RCM continually receives and monitors inputs from the OCSM and various other hard-wired switches and sensors. If the RCM detects a sudden vehicle deceleration and/or lateral deceleration based on the information received from the various sensors and determines that deployment is necessary, it applies voltage and current to deploy the appropriate SRS components...
