Ford Escape: Electronic Engine Controls / Description and Operation - Electronic Engine Controls - Component Location

LH Engine Sensor Locations


Item Description
1 CHT sensor
2 CMP sensor
3 KS
4 MAPT sensor
5 VCT oil control solenoid

Electronic Engine Controls - RH


Item Description
1 Catalyst monitor sensor
2 CKP sensor
3 HO2S

Powertrain Control Module (PCM)


Item Description
1 PCM

Engine Coolant Temperature (ECT3) and (ECT4)


Item Description
1 Engine coolant Temperature (ECT3) sensor
2 Engine coolant Temperature (ECT4) sensor

    Description and Operation - Electronic Engine Controls - Overview

    Overview The EEC system provides optimum control of the engine through the enhanced capability of the powertrain control module (PCM). The EEC system also has an on board diagnostic (OBD) monitoring system with features and functions to meet federal regulations on exhaust emissions...

    Description and Operation - Electronic Engine Controls - System Operation and Component Description

    System Operation Comprehensive Component Monitor (CCM) The comprehensive component monitor (CCM) checks for concerns in any powertrain electronic component or circuit that provides input or output signals to the PCM that can affect emissions and is not monitored by another OBD monitor...
