Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Front Door Speaker
Removal
NOTE:
Removal steps in this procedure may contain installation details.
NOTE:
LH front door speaker is shown, RH side front door speaker is similar.
-
Remove the LH front door interior trim panel.
Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
-
Disconnect the electrical connector, remove the screws and the LH front door speaker.
Torque:
13 lb.in (1.5 Nm)
Installation
-
To install, reverse the removal procedure.
