Ford Escape 2020-2025 Service Manual / Powertrain / Engine / Engine / Description and Operation - Engine Component View
Ford Escape: Engine / Description and Operation - Engine Component View
Lower Engine Block (View 1)
| Item | Part Number | Description |
|---|---|---|
| 1 | 60156015 | Cylinder block |
| 2 | 6K3186K318 | Crankshaft rear oil seal and retainer |
| 3 | 6K3906K390 | Flywheel |
| 4 | 75507550 | Damper |
| 5 | 66766676 | Oil pan |
| 6 | 67146714 | Oil filter |
| 7 | 68846884 | Oil filter adapter |
| 8 | 6B8566B856 | Oil filter cooler |
| 9 | 6A6366A636 | Oil filter adapter gasket |
| 10 | 92789278 | Engine Oil Pressure (EOP) switch |
| 11 | 6A7856A785 | Crankcase vent oil separator |
| 12 | 8K5288K528 | Cooling inlet cover |
| 13 | 8K5308K530 | Cooling inlet cover gasket |
| 14 | 66226622 | Oil pump screen and pickup tube |
Lower Engine Block (View 2)
| Item | Part Number | Description |
|---|---|---|
| 1 | 6K3606K360 | Balance shaft assembly |
| 2 | — | Main bearing beam (part of 6010) |
| 3 | 6A3386A338 | Crankshaft main bearing beam bearing (5 required) |
| 4 | 63006300 | Crankshaft assembly |
| 5 | 63336333 | Cylinder block crankshaft main bearing (4 required) |
| 6 | 63376337 | Cylinder block crankshaft main thrust bearing |
| 7 | 61106110 | Piston (4 required) |
Front Engine Block
| Item | Part Number | Description |
|---|---|---|
| 1 | 6N3046N304 | Crankshaft pulley cover |
| 2 | 6C3156C315 | Crankshaft Position (CKP) sensor |
| 3 | 6K3406K340 | Crankshaft pulley bolt |
| 4 | 63166316 | Crankshaft pulley |
| 5 | 60596059 | Engine front cover |
| 6 | 8B5938B593 | Coolant cover assembly |
| 7 | 6K2546K254 | Timing chain tensioner |
| 8 | 6K2556K255 | Timing chain tensioner arm |
| 9 | 62686268 | Timing chain |
| 10 | 6K2976K297 | Timing chain guide |
| 11 | 6C2716C271 | Oil pump chain tensioner |
| 12 | 6A8956A895 | Oil pump chain |
| 13 | 66526652 | Oil pump drive gear |
| 14 | 67006700 | Crankshaft front seal |
| 15 | 63066306 | Crankshaft sprocket |
| 16 | 66006600 | Oil pump |
Cylinder Head
.jpg)
| Item | Part Number | Description |
|---|---|---|
| 1 | 12A37512A375 | Coil-on-plug assembly (4 required) |
| 2 | 1240512405 | Spark plug (4 required) |
| 3 | 67666766 | Oil filler cap |
| 4 | 12K07312K073 | CMP sensor |
| 5 | 6K2716K271 | Valve cover |
| 6 | 6K2606K260 | Valve cover gasket |
| 7 | 6B2976B297 | VCT oil control solenoid |
| 8 | 6G0046G004 | CHT sensor |
| 9 | 6B2826B282 | Mega cap |
| 10 | 6A2846A284 | Camshaft bearing cap (8 required) |
| 11 | 6A2726A272 | Camshaft (exhaust) |
| 12 | 6A2676A267 | Camshaft (intake) |
| 13 | 6C2516C251 | Camshaft sprocket |
| 14 | 6C5246C524 | VCT actuator |
| 15 | 65006500 | Valve tappet (16 required) |
| 16 | 65186518 | Valve collet (32 required) |
| 17 | 65146514 | Valve spring retainer (16 required) |
| 18 | 65136513 | Valve spring (16 required) |
| 19 | 6A5176A517 | Valve stem seal (16 required) |
| 20 | 60496049 | Cylinder head |
| 21 | 65056505 | Exhaust valve (8 required) |
| 22 | 65076507 | Intake valve (8 required) |
| 23 | 60516051 | Head gasket |
| 24 | 60156015 | Cylinder block |
Intake Manifold
.jpg)
| Item | Part Number | Description |
|---|---|---|
| 1 | 9F4649F464 | EGR cooler |
| 2 | 9D4759D475 | EGR valve |
| 3 | 9E4709E470 | EGR outlet tube |
| 4 | 8K5568K556 | Coolant outlet |
| 5 | 60516051 | Cylinder head gasket |
| 6 | 12A69912A699 | Knock Sensor (KS) |
| 7 | 9F9919F991 | Electronic throttle body |
| 8 | 94249424 | Intake manifold |
| 9 | 94399439 | Intake manifold gasket |
| 10 | 9J3289J328 | Fuel supply tube |
| 11 | 9F5939F593 | Fuel injector (4 required) |
| 12 | 9H4879H487 | Fuel rail |
| 13 | 70817081 | Blanking plate |
| 14 | 60496049 | Cylinder head |
Diagnosis and Testing - Engine
For gas engine mechanical diagnosis and testing, REFER to: Engine (303-00 Engine System - General Information, Diagnosis and Testing). For DTC (Diagnostic Trouble Code) related concerns, REFER to the Master DTC Chart...
