Ford Escape 2020-2026 Service Manual / Chassis / Brake System / Parking Brake and Actuation / Description and Operation - Parking Brake - Component Location
Ford Escape: Parking Brake and Actuation / Description and Operation - Parking Brake - Component Location
Vehicles with vacuum brake booster
| Item | Description |
|---|---|
| 1 | ABS module |
| 2 | Parking brake switch |
| 3 | Parking brake actuator motor (2 required) |
Vehicles with electric brake booster
| Item | Description |
|---|---|
| 1 | ABS module |
| 2 | Parking brake switch |
| 3 | Parking brake actuator motor (2 required) |
Description and Operation - Parking Brake - Overview
Overview
The
parking brake system uses 2 switch activated, Electronic Control Unit
(ECU) controlled motors to apply and release the rear brake calipers...
