Ford Escape: Rear Drive Axle/Differential / Description and Operation - Rear Drive Axle and Differential - Component Location
RDU - Component Location
| Item |
Description |
| 1 |
RDU actuator motor |
| 2 |
Speed sensor |
| 3 |
RDU
|
| 4 |
AWD module |
| 5 |
PTU (Power transfer unit) |
Materials
Name
Specification
XY-75W-QL - Motorcraft® Disconnect Rear Drive Unit Fluid
-
Premium Long-Life Grease XG-1-E1
ESA-M1C75-B
Capacities
Item
Liters
Material: Motorcraft® Disconnect Rear Drive Unit Fluid
/ XY-75W-QL
0...
The RDU is available with 2.58 drive ratio.
Rear Drive Axle and Differential
The rear drive axle and differential unit (RDU ) is a cast aluminum
differential assembly located in the rear of the vehicle consisting of
the following components:
Crown wheel and pinion
An electrically activated and mechanically engaged
clutch pack acting on the rear drive axles, that applies or removes..
