Ford Escape: Transmission Cooling - Automatic Transmission – HF45 / Description and Operation - Transmission Cooling - Plug-In Hybrid Electric Vehicle (PHEV)

Component Location


Item Part Number Description
1 7A0957A095 Transmission fluid cooler
2 7H4207H420 Transmission fluid cooler tube assembly
3 7P0867P086 Transmission fluid auxiliary pump
4 7A0317A031 Transmission fluid auxiliary pump inlet tube

    Description and Operation - Transmission Cooling - Hybrid Electric Vehicle (HEV) - Overview

    Overview The transmission fluid cooling system consists of the following: Transmission fluid cooler tubes Transmission fluid cooler This vehicle is equipped with an external air cooled transmission fluid cooler...

    Description and Operation - Transmission Cooling - Plug-In Hybrid Electric Vehicle (PHEV) - Overview

    Overview The transmission fluid cooling system consists of the following: Transmission fluid cooler tubes Transmission fluid cooler Transmission fluid auxiliary pump Transmission fluid auxiliary pump inlet tube This vehicle is equipped with an external transmission fluid cooler...
