Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Antenna Isolator Module
Special Tool(s) /
General Equipment
Removal
NOTE:
Removal steps in this procedure may contain installation details.
NOTE:
LH isolator is shown, RH isolator is similar.
-
Release the clips, the trim anchors and remove the center upper liftgate interior trim panel.
Use the General Equipment: Interior Trim Remover
-
Release the clips, the trim anchors and remove the LH upper liftgate interior trim panel.
Use the General Equipment: Interior Trim Remover
-
Disconnect the electrical connectors, remove the bolt and the antenna isolator.
Torque:
93 lb.in (10.5 Nm)
Installation
-
To install, reverse the removal procedure.
