Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Audio Controls

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the information and entertainment display unit.
    Refer to: Center Display Screen (415-00 Information and Entertainment System - General Information, Removal and Installation).
  1. Remove the bolts.
    Torque: 22 lb.in (2.5 Nm)

  1. Release the clips, disconnect the electrical connector and remove the center upper instrument panel finish panel.
    • Remove and discard the retaining clips. Install new retaining clips.
      Use the General Equipment: Interior Trim Remover
  1. Remove the screws and the audio controls.
    Torque: 13 lb.in (1.5 Nm)

Installation

  1. To install, reverse the removal procedure.
