Ford Escape: Roof Opening Panel / Removal and Installation - Roof Opening Panel Center Beam Trim
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Pulling downward, remove the cross beam cover.
Refer to: Roof Opening Panel Glass (501-17 Roof Opening Panel, Removal and Installation).
-
Pulling downward, remove the cross beam cover.
Installation
NOTE:
Using a isopropyl alcohol wipes, clean the remaining adhesive from the frame.
-
To install, reverse the removal procedure.
