Ford Escape: Engine / General Procedures - Engine Oil Draining and Filling
Special Tool(s) /
General Equipment
Draining
-
With the vehicle in NEUTRAL, position it on a hoist.
Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).
-
Remove the fasteners and the undershield.
-
-
Remove the oil pan drain plug and drain the engine oil.
Use the General Equipment: Oil Drain Equipment
-
Install the oil drain plug.
Torque:
21 lb.ft (28 Nm)
-
Remove and discard the engine oil filter.
Use the General Equipment: Oil Drain Equipment
Filling
-
Install a new oil filter.
Torque:
133 lb.in (15 Nm)
-
Install the underbody shield and fasteners.
-
Fill the engine with clean engine oil.
Refer to: Specifications (303-01C Engine, Specifications).
Special Tool(s) /
General Equipment
Feeler Gauge
Check
Refer to: Valve Cover (303-01C Engine, Removal and Installation).
NOTE:
Turn the engine clockwise only, and only use the crankshaft bolt...
Special Tool(s) /
General Equipment
303-465Tool, Camshaft Align TimingTKIT-1994-LMH/MH2TKIT-1994-FH/FMH/FLMH
303-507Timing Peg, Crankshaft TDCTKIT-2001N-FLMTKIT-2001N-ROW
Feeler Gauge
Removal
NOTE:
During engine repair procedures, cleanliness is extremely
important...
Other information:
Pre-Collision Assist Precautions
WARNING: You are responsible for
controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death...
System Operation
BLIS ® and CTA
System Diagram - Vehicles Without Door Modules
Item
Description
1
SODL
2
GWM
3
SCCM
4
PAM
5
IPC
6
APIM
7
PCM
8
TRM (If equipped)
9
BCM
10
ACM
11
LH exterior mirror
12
DSP Module
13
10 Speaker System
