Ford Escape: Exterior Lighting / Headlamps

Using the High Beam Headlamps

Ford Escape. Headlamps

Ford Escape. Headlamps Push the lever away from you to switch the high beams on.

Push the lever forward again or pull the lever toward you to switch the high beams off.

Slightly pull the lever toward you and release it to flash the headlamps.

Switching Headlamp Exit Delay On and Off

To switch headlamp exit delay on, pull the turn signal lever toward you after switching your vehicle off.

To switch headlamp exit delay off, pull the turn signal lever toward you again or switch your vehicle on.

Note: The headlamps turn off after three minutes with any door open or 30 seconds after the last door closes.

Headlamp Indicators

Lamps On

Ford Escape. Headlamps Illuminates when you switch the low beam headlamps or the parking lamps on.

Headlamp High Beam

Ford Escape. Headlamps Illuminates when you switch the high beam headlamps on.

    Exterior Lighting Control

    Lamps off. Parking lamps on. Autolamps on. Headlamps on. Rotate the control to make a selection. Note: The lighting control defaults to autolamps every time you switch your vehicle on...

    Headlamps – Troubleshooting

    Headlamps – Frequently Asked Questions Why is there condensation in the headlamps? Headlamps have vents to accommodate normal changes in air pressure...
