Other information:
Removal
NOTE:
LH (left-hand) side shown, RH (right-hand) side similar.
Remove the rear door window regulator and motor.
Refer to: Rear Door Window Regulator and Motor (501-11 Glass, Frames and Mechanisms, Removal and Installation).
Remove the exterior rear door handle.
Refer to: Exterior Rear Door Handle (501-14 Handles, Locks, Latches and Entry Systems, Removal and I..
Special Tool(s) /
General Equipment
Interior Trim Remover
Removal
Remove the floor console.
Refer to: Floor Console (501-12 Instrument Panel and Console, Removal and Installation).
Remove the instrument panel center register.
Refer to: Center Registers (412-00 Climate Control System - General Information, Removal and Installation).
Release the cl..
