Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Audio Digital Signal Processing (DSP) Module

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. NOTE: If installing a new module, it is necessary to upload the module configuration information to the scan tool prior to removing the module. This information must be downloaded into the new module after installation.

    Using a diagnostic scan tool, begin the PMI process for the DSP following the on-screen instructions.
  1. Remove the RH loadspace trim panel.
    Refer to: Loadspace Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
  1. Remove the bolts and position the DSP up and out.
    Torque: 62 lb.in (7 Nm)
  1. Disconnect the electrical connectors, remove the screws and the DSP .

Installation

  1. To install, reverse the removal procedure.
  1. NOTE: This step is only necessary when installing a new component.

    Using a diagnostic scan tool, complete the PMI process for the DSP following the on-screen instructions.
