Ford Escape 2020-2026 Service Manual / Chassis / Brake System / Hydraulic Brake Actuation / Removal and Installation - Brake Fluid Reservoir - Vehicles With: Vacuum Brake Booster

Ford Escape: Hydraulic Brake Actuation / Removal and Installation - Brake Fluid Reservoir - Vehicles With: Vacuum Brake Booster

Removal

NOTE: Removal steps in this procedure may contain installation details.

Remove the brake master cylinder.
Refer to: Brake Master Cylinder - Vehicles With: Vacuum Brake Booster (206-06 Hydraulic Brake Actuation, Removal and Installation).

Remove the brake fluid reservoir cap and syphon the brake fluid..

Remove the pin and the brake fluid reservoir.

Remove and discard the brake fluid reservoir seals.

Installation

To install, reverse the removal procedure.
