Ford Escape: Climate Control System - General Information / Removal and Installation - Driver Side Footwell Air Discharge Temperature Sensor
Removal
-
Remove the driver knee aitbag.
Refer to: Driver Knee Airbag (501-20B Supplemental Restraint System, Removal and Installation).
-
NOTE:
Acessed behind the lower trim panel.
-
Disconnect the electrical connector.
-
Roate the sensor and remove.
Installation
-
To install, reverse the removal procedure.
