Ford Escape: Instrument Panel and Console / Removal and Installation - Floor Console
Special Tool(s) /
General Equipment
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Release the clips and remove the trim panel.
-
Disconnect the electrical connectors.
-
Release the clips and remove the RH floor console side trim panel.
Use the General Equipment: Interior Trim Remover
-
NOTE:
LH side of floor console.
-
Remove the cover.
-
Remove the bolt.
-
Release the clips and remove the LH floor console side trim panel.
-
Remove the bolts, release the clips and harness retainers and remove the trim panel.
-
Disconnect the electrical connector.
-
Release the clips and remove the rear floor console trim panel.
-
Disconnect the electrical connector.
-
NOTE:
LH side of floor console.
Disconnect the electrical connector, detach the harness retainer and position aside the harness.
-
Remove the bolts and remove the floor console.
-
Disconnect the electrical connector, detach the harness retainer and position aside the harness.
Installation
-
To install, reverse the removal procedure.
-
NOTE:
Anytime the parking brake switch electrical
connector has been disconnected, the EPB (electric parking brake) system
is deactivated and a DTC (diagnostic trouble code) is stored in the ABS
(anti-lock brake system) module. Perform the following EPB (electric
parking brake) step to restore the system and clear the ABS (anti-lock
brake system) module DTC (diagnostic trouble code).
Apply and release the parking brake twice within 5
seconds, pausing with the switch in the NEUTRAL position for
approximately one-half second between each apply and release.
