System Operation
Rear Only Parking Aid Camera
System Diagram
Item
Description
1
PAM
2
ABS module
3
PSCM
4
GWM
5
BCM
6
PCM
7
TRM
8
Rear parking aid camera
9
video signal
10
APIM
11
Audio system display
Network Message Chart
BCM Network Input Mess..
Special Tool(s) /
General Equipment
Door Lift
Removal
NOTE:
Removal steps in this procedure may contain installation details.
NOTE:
LH side shown, RH side similar.
Open the door.
Remove the rear door check arm bolt.
Torque:
18 lb.ft (25 Nm)
Disconnect the rear door electrical connectors.
..
