Ford Escape: Glass, Frames and Mechanisms / Removal and Installation - Front Door Glass Top Run
Removal
NOTE:
LH (left-hand) side shown, RH (right-hand) side similar.
NOTE:
Removal steps in this procedure may contain installation details.
-
Remove the front door window glass.
Refer to: Front Door Window Glass (501-11 Glass, Frames and Mechanisms, Removal and Installation).
-
Remove the exterior mirror.
Refer to: Exterior Mirror (501-09 Rear View Mirrors, Removal and Installation).
-
Remove the front door window regulator and motor.
Refer to: Front Door Window Regulator and Motor (501-11 Glass, Frames and Mechanisms, Removal and Installation).
-
Remove the front door outer belt moulding screws.
-
Remove the fore front door outer belt moulding screw.
Torque:
12 lb.in (1.3 Nm)
-
Remove the aft front door outer belt moulding screw.
Torque:
12 lb.in (1.3 Nm)
-
Remove the front door outer belt moulding.
-
Remove the front door glass top run screw.
Torque:
12 lb.in (1.3 Nm)
-
Remove the front door glass top run screw.
Torque:
12 lb.in (1.3 Nm)
-
Remove the front door glass top run.
-
Release the front door glass top run from the door run channel.
-
Release the front door glass top run from the door run channel.
-
Release the front door glass top run from the door run channel.
-
Remove the front door glass top run.
Installation
-
To install, reverse the removal procedure.
-
If the door is equipped with one touch up/down, carry out the power
door window initialization.
Refer to: Power Door Window Initialization - Vehicles With: One-Touch
Open and Close Front Windows (501-11 Glass, Frames and Mechanisms,
General Procedures).
