Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Center Display Screen
Special Tool(s) /
General Equipment
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Release the clips and remove the display unit rear trim panel.
Use the General Equipment: Interior Trim Remover
-
Remove the bolts and position the information and entertainment display panel up.
Torque:
22 lb.in (2.5 Nm)
-
Disconnect the LVDS cable connector and remove the information and entertainment display panel.
Installation
-
To install, reverse the removal procedure.
