Ford Escape: Module Communications Network / Removal and Installation - Gateway Module A (GWM)
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
NOTE:
If installing a new module, it is necessary to
upload the module configuration information to the scan tool prior to
removing the module. This information must be downloaded into the new
module after installation.
Using a diagnostic scan tool, begin the PMI process for the GWM following the on-screen instructions.
-
-
Remove the nuts.
Torque:
28 lb.in (3.2 Nm)
-
Disconnect the electrical connector and remove the GWM .
Installation
-
To install, reverse the removal procedure.
-
Using a diagnostic scan tool, complete the PMI process for the GWM following the on-screen instructions.
