Ford Escape: Automatic Transmission - Automatic Transmission – HF45 / Removal and Installation - Halfshaft Seal RH - FWD
Special Tool(s) /
General Equipment
.jpg) |
205-153
(T80T-4000-W)
Handle |
.jpg) |
307-758 Installer, Axle Seal -FWD |
Flat Headed Screw Driver |
Removal
-
With the vehicle in NEUTRAL, position it on a hoist.
Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).
-
Remove the front RH halfshaft.
Refer to: Front Halfshaft RH - 2.5L Duratec – Hybrid (121kW/164PS) (BG)
(205-04 Front Drive Halfshafts, Removal and Installation).
-
Remove and discard the RH halfshaft seal.
Use the General Equipment: Flat Headed Screw Driver
Installation
-
Install a new halfshaft seal on the special tools.
Use Special Service Tool: 205-153
(T80T-4000-W)
Handle.
, 307-758
Installer, Axle Seal -FWD.
-
Using the special tools, install the RH halfshaft seal.
Use Special Service Tool: 205-153
(T80T-4000-W)
Handle.
, 307-758
Installer, Axle Seal -FWD.
-
Install the front RH halfshaft.
Refer to: Front Halfshaft RH - 2.5L Duratec – Hybrid (121kW/164PS) (BG)
(205-04 Front Drive Halfshafts, Removal and Installation).
-
Check the transmission fluid level.
Refer to: Transmission Fluid Level Check (307-01B Automatic Transmission - Automatic Transmission – HF45, General Procedures).
