Ford Escape 2020-2024 Service Manual / Powertrain / Automatic Transmission / Automatic Transmission - Automatic Transmission – HF45 / Removal and Installation - Halfshaft Seal RH - AWD

Ford Escape: Automatic Transmission - Automatic Transmission – HF45 / Removal and Installation - Halfshaft Seal RH - AWD

Special Tool(s) / General Equipment

	205-153 (T80T-4000-W) Handle
	307-758 Installer, Axle Seal -FWD
Flat Headed Screw Driver

Removal

Remove the power transfer unit.
Refer to: Power Transfer Unit (308-07E) .

Remove and discard the RH halfshaft seal.
Use the General Equipment: Flat Headed Screw Driver

Installation

Install a new halfshaft seal on the special tools.
Use Special Service Tool: 205-153 (T80T-4000-W) Handle. , 307-758 Installer, Axle Seal -FWD.

Using the special tools, install the RH halfshaft seal.
Use Special Service Tool: 205-153 (T80T-4000-W) Handle. , 307-758 Installer, Axle Seal -FWD.

Install the power transfer unit.
Refer to: Power Transfer Unit (308-07E) .

Check the transmission fluid level.
Refer to: Transmission Fluid Level Check (307-01B Automatic Transmission - Automatic Transmission – HF45, General Procedures).
