Ford Escape: Electric Powertrain Control / Removal and Installation - High Voltage Battery Coolant Temperature Sensor
Removal
-
NOTE:
Removal steps in this procedure may contain installation details.
Drain the Electric Powertrain Cooling System.
Refer to: Cooling System Filling and Bleeding (303-03D Electric
Powertrain Cooling - Hybrid Electric Vehicle (HEV), General Procedures).
-
-
Remove the retainers and the RH underbody shield.
Torque:
22 lb.in (2.5 Nm)
-
Remove the nuts.
Torque:
55 lb.in (6.2 Nm)
-
Disconnect the electrical connector. Remove the clip and the high voltage battery coolant temperature sensor.
Installation
-
To install, reverse the removal procedure.
-
Fill the Electric Powertrain Cooling System
Refer to: Cooling System Filling and Bleeding (303-03D Electric
Powertrain Cooling - Hybrid Electric Vehicle (HEV), General Procedures).
