Ford Escape: High Voltage Battery, Mounting and Cables / Removal and Installation - High Voltage Battery Junction Box - Hybrid Electric Vehicle (HEV)
Removal
WARNING:
To prevent the risk of high-voltage shock, always follow
precisely all warnings and service instructions, including instructions
to depower the system. The high-voltage system utilizes approximately
450 volts DC, provided through high-voltage cables to its components and
modules. The high-voltage cables and wiring are identified by orange
harness tape or orange wire covering. All high-voltage components are
marked with high-voltage warning labels with a high-voltage symbol.
Failure to follow these instructions may result in serious personal
injury or death.
NOTE:
All gaskets and sealing surfaces must be clean and free of all foreign matter prior to assembly.
-
WARNING:
Before beginning any service procedure in this
section, refer to Safety Warnings in section 100-00 General Information.
Failure to follow this instruction may result in serious personal
injury.
Refer to: High Voltage System Health and Safety Precautions - Overview (100-00 General Information, Description and Operation).
-
Remove the high voltage battery.
Refer to: High Voltage Battery - Hybrid Electric Vehicle (HEV) (414-03A
High Voltage Battery, Mounting and Cables, Removal and Installation).
-
Remove the fasteners and the high voltage battery cover.
-
Disconnect the electrical connectors from the high voltage battery junction box.
-
-
Release the high voltage battery junction box electrical connectors locking tabs.
-
Disconnect the electrical connectors from the high voltage battery junction box.
-
Detach the retainers from the high voltage battery junction box and position the wire harness aside.
-
Remove the high voltage battery junction box bolts.
-
Remove the bolt and the high voltage battery junction box.
Installation
-
NOTE:
Inspect the seals for correct position and or damage.
-
NOTE:
The bolt is only finger-tight in this step.
Install the high voltage battery junction box and the bolt finger-tight.
-
Install the high voltage battery junction box bolts in the sequence shown.
Torque:
62 lb.in (7 Nm)
-
Tighten the high voltage battery junction box bolt.
Torque:
62 lb.in (7 Nm)
-
NOTICE:
To ensure the wire harness is proper secured, remove
the stem portion of the wire harness retainer and install a new wire
harness retainer as shown.
-
Remove the stem portion of the wire harness retainer.
-
Attach a new retainer to the wire harness.
-
Position the wire harness and attach the retainers to the high voltage battery junction box.
-
-
Connect the electrical connectors to the high voltage battery junction box.
-
Position the high voltage battery junction box electrical connectors locking tabs.
-
Connect the electrical connectors to the high voltage battery junction box.
-
NOTE:
Inspect the high voltage battery cover seal and replace with a new seal if necessary.
-
NOTE:
This step is only required if you are replacing the high voltage battery cover seal.
Install the new high voltage battery cover seal.
-
NOTE:
Finger-start the bolts.
-
Install the high voltage battery cover and tighten the bolts in the sequence shown.
Torque:
Stage 1:
62 lb.in (7 Nm)
Stage 2:
18 lb.ft (25 Nm)
-
Install the high voltage battery.
Refer to: High Voltage Battery - Hybrid Electric Vehicle (HEV) (414-03A
High Voltage Battery, Mounting and Cables, Removal and Installation).
