Ford Escape: Exterior Lighting / Removal and Installation - License Plate Lamp
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Remove the liftgate trim panel.
Refer to: Liftgate Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
-
Disconnect the electrical connectors, release the tabs and remove the license plate lamp.
Installation
-
To install, reverse the removal procedure.
