Ford Escape: Exterior Lighting / Removal and Installation - High Mounted Stoplamp
Special Tool(s) /
General Equipment
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Remove the rear spoiler.
Refer to: Rear Spoiler (501-08 Exterior Trim and Ornamentation, Removal and Installation).
-
Remove the high mounted stoplamp from the rear spoiler.
-
Using a interior trim removal tool, release the clips.
Use the General Equipment: Interior Trim Remover
-
Disconnect the high mounted stoplamp electrical
connector and washer fluid hose. Remove the high mounted stoplamp.
Installation
-
To install, reverse the removal procedure.
