Ford Escape 2020-2026 Service Manual / Electrical / Instrumentation and Warning Systems / Pedestrian Alert System / Removal and Installation - Pedestrian Alert Control Module (PACM)

Ford Escape: Pedestrian Alert System / Removal and Installation - Pedestrian Alert Control Module (PACM)

Removal

Remove the RH side loadspace trim panel.
Refer to: Loadspace Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

1. Disconnect the electrical connector.
1. Release the wiring guide from the bracket.
1. Remove the bolts and the PACM .
  Torque: 71 lb.in (8 Nm)

Installation

To install, reverse the removal procedure.
