Ford Escape: Exterior Lighting / Removal and Installation - Rear Lamp Bulb
Removal
NOTE:
Left hand rear lamp assembly shown, right hand rear lamp assembly similar.
Turn signal bulb
-
Remove the rear lamp assembly.
Refer to: Rear Lamp Assembly (417-01 Exterior Lighting, Removal and Installation).
-
While turning counter clockwise, remove the turn signal bulb holder socket.
-
Remove the turn signal bulb.
Side marker bulb
-
Remove the rear lamp assembly.
Refer to: Rear Lamp Assembly (417-01 Exterior Lighting, Removal and Installation).
-
While turning counter clockwise, remove the side marker bulb holder socket.
-
Remove the side marker bulb.
Installation
-
To install, reverse the removal procedure.
