Ford Escape: Exterior Trim and Ornamentation / Removal and Installation - Roof Moulding
Removal
NOTE:
Removal steps in this procedure may contain installation details.
NOTE:
LH side shown, RH side similar.
-
Lower the headliner.
Refer to: Headliner - Lowering (501-05 Interior Trim and Ornamentation, Removal and Installation).
-
On both sides.
Remove the nuts.
Torque:
89 lb.in (10 Nm)
-
Remove the liftegate hinge cover and and roof moulding.
Installation
-
To install, reverse the removal procedure.
