Other information:
Removal
NOTICE:
During the removal or installation of components, cap, tape
or otherwise appropriately protect all openings and tubes/fittings to
prevent the ingress of dirt or other contamination. Remove caps, tape
and other protective materials prior to installation.
NOTE:
Removal steps in this procedure may contain installation details.
Recover the refrigerant. Refer to th..
System Operation
System Diagram
Item
Description
1
GWM
2
Ambient Air Temperature (AAT) sensor
3
PCM
4
A/C pressure transducer
5
A/C clutch relay
6
A/C compressor clutch field coil
7
HVAC Control Module
8
Air distribution door actuator
9
Temperature door actuator
10
Air inlet door actuator
11..
