Ford Escape 2020-2026 Service Manual / Electrical / Climate Control System / Supplemental Climate Control / Description and Operation - Supplemental Climate Control - Component Location

Ford Escape: Supplemental Climate Control / Description and Operation - Supplemental Climate Control - Component Location


Item Description
1 Front evaporator shutoff valve
2 High voltage battery coolant cooler
3 Electric booster heater

Plug-In Hybrid Electric Vehicle (PHEV)


Item Description
1 Cabin heater coolant temperature sensor
2 Cabin coolant heater
3 Cabin heater coolant diverter valve
4 Cabin heater coolant pump

    Supplemental Climate Control

    ..

    Description and Operation - Supplemental Climate Control - Overview

    Overview The electric booster heater, if equipped, is used to heat the passenger compartment during low ambient temperatures when the heater core cannot provide sufficient heat due to low engine coolant temperatures...
