Overview

The transmission fluid cooling system consists of the following:

  • Transmission fluid cooler tubes
  • Transmission fluid cooler
  • Transmission fluid auxiliary pump
  • Transmission fluid auxiliary pump inlet tube

This vehicle is equipped with an external transmission fluid cooler. Transmission fluid flows from the transmission through the transmission fluid cooler tube to the transmission fluid cooler. This vehicle also has an electric auxiliary transmission fluid pump to circulate the transmission fluid during extended drive times without engine charging. The auxiliary transmission fluid pump transfers transmission fluid to the transmission fluid cooler via the transmission fluid cooler tubes.

Component Location


Item Description
1 Transmission fluid cooler
2 Transmission fluid cooler tube assembly
3 Transmission fluid auxiliary pump
4 Transmission fluid auxiliary pump inlet tube
