Ford Escape: Fuel Charging and Controls / Diagnosis and Testing - Fuel Charging

Diagnostic Trouble Code (DTC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).

Module	DTC	Description	Action
PCM	P0201:00	Cylinder 1 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P0202:00	Cylinder 2 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P0203:00	Cylinder 3 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P0204:00	Cylinder 4 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P0205:00	Cylinder 5 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P0206:00	Cylinder 6 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P0207:00	Cylinder 7 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P0208:00	Cylinder 8 Injector 'A' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P2149:00	Fuel Injector Group 'B' Supply Voltage Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21CF:00	Cylinder 1 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21D0:00	Cylinder 2 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21D1:00	Cylinder 3 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21D2:00	Cylinder 4 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21D3:00	Cylinder 5 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21D4:00	Cylinder 6 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21D5:00	Cylinder 7 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P21D6:00	Cylinder 8 Injector 'B' Circuit/Open: No Sub Type Information	GO to Pinpoint Test KG
PCM	P2C27:00	Fuel Injector Group 'B' Supply Sense Circuit Low: No Sub Type Information	GO to Pinpoint Test KG
PCM	P2C28:00	Fuel Injector Group 'B' Supply Sense Circuit High: No Sub Type Information	GO to Pinpoint Test KG

Symptom Chart

Symptom	Possible Sources	Action
The engine runs rough at idle.	Refer to the pinpoint test.	GO to Pinpoint Test KG

Pinpoint Tests

PINPOINT TEST KG: FUEL INJECTOR

Introduction

Normal Operation and Fault Conditions

Refer to the DTC Fault Trigger Conditions.

DTC Fault Trigger Conditions

DTC	Description	Fault Trigger Condition
PCM P0201:00	Cylinder 1 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P0202:00	Cylinder 2 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P0203:00	Cylinder 3 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P0204:00	Cylinder 4 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P0205:00	Cylinder 5 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P0206:00	Cylinder 6 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P0207:00	Cylinder 7 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P0208:00	Cylinder 8 Injector 'A' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM
PCM P2149:00	Fuel Injector Group 'B' Supply Voltage Circuit/Open: No Sub Type Information	Sets when the PCM detects the injector relay voltage is less than the calibrated threshold. This DTC also sets when a concern is detected in the INJRLY circuit.
PCM P21CF:00	Cylinder 1 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P21D0:00	Cylinder 2 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P21D1:00	Cylinder 3 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P21D2:00	Cylinder 4 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P21D3:00	Cylinder 5 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P21D4:00	Cylinder 6 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P21D5:00	Cylinder 7 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P21D6:00	Cylinder 8 Injector 'B' Circuit/Open: No Sub Type Information	Sets when the PCM detects the fuel injector circuitry is inoperative. The comprehensive component monitor (CCM) monitors the operation of the fuel injector drivers in the PCM .
PCM P2C27:00	Fuel Injector Group 'B' Supply Sense Circuit Low: No Sub Type Information	Sets when the PCM detects the injector relay voltage is less than the calibrated threshold. This DTC also sets when a concern is detected in the injector relay (INJRLY) circuit or the injector power monitor (INJPWRM) circuit.
PCM P2C28:00	Fuel Injector Group 'B' Supply Sense Circuit High: No Sub Type Information	Sets when the PCM detects the INJRLY circuit voltage is more than the calibrated threshold. This DTC also sets when the injector power monitor (INJPWRM) circuit voltage is more than the calibrated threshold.

Possible Sources

Fuel injector relay
Fuel injector (9F593)
PCM (12A650)
