Ford Escape 2020-2024 Service Manual / Powertrain / Engine / Fuel Charging and Controls - Turbocharger - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / Diagnosis and Testing - Turbocharger Controls

Ford Escape: Fuel Charging and Controls - Turbocharger - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / Diagnosis and Testing - Turbocharger Controls

Diagnostic Trouble Code (DTC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).

Module	DTC	Description	Action
PCM	P0234:00	Turbocharger/Supercharger 'A' Overboost Condition: No Sub Type Information	GO to Pinpoint Test HN
PCM	P0245:00	Turbocharger/Supercharger Wastegate Actuator 'A' Low: No Sub Type Information	GO to Pinpoint Test HN
PCM	P0246:00	Turbocharger/Supercharger Wastegate Actuator 'A' High: No Sub Type Information	GO to Pinpoint Test HN
PCM	P0299:00	Turbocharger/Supercharger 'A' Underboost Condition: No Sub Type Information	GO to Pinpoint Test HN

Global Customer Symptom Code (GCSC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).

Symptom	Action
Driving Performance > Lack/Loss of Power > Acceleration > Always	GO to Pinpoint Test HN
Driving Performance > Lack/Loss of Power > Cruise/ Steady Speed > Always	GO to Pinpoint Test HN

Pinpoint Tests

PINPOINT TEST HN: TURBOCHARGER SYSTEM

Introduction

NOTE: To recreate the original conditions that set the DTC or caused the symptom, the vehicle may require driving.

Normal Operation and Fault Conditions

Refer to the DTC Fault Trigger Conditions.

DTC Fault Trigger Conditions

DTC	Description	Fault Trigger Condition
PCM P0234:00	Turbocharger/Supercharger 'A' Overboost Condition: No Sub Type Information	This DTC sets when the turbocharger system TCBP PID value is greater than a calibrated threshold, or the turbocharger system TCBP PID value is greater than the turbocharger boost pressure (TCBP) desired value for a calibrated length of time. Check tubing for restrictions, cracks and incorrect fitting connections. Check the turbocharger wastegate regulating valve solenoid for correct operation.
PCM P0245:00	Turbocharger/Supercharger Wastegate Actuator 'A' Low: No Sub Type Information	Sets when the PCM detects an open circuit or a short to ground from the TCWRVS circuit. This DTC only sets when the solenoid valve is energized.
PCM P0246:00	Turbocharger/Supercharger Wastegate Actuator 'A' High: No Sub Type Information	Sets when the PCM detects high voltage from the TCWRVS circuit. This DTC only sets when the solenoid valve is energized.
PCM P0299:00	Turbocharger/Supercharger 'A' Underboost Condition: No Sub Type Information	Sets when the PCM detects the actual turbocharger boost pressure (TCBP) value is less than the desired turbocharger boost pressure (TCBP) value by 27.6 kPa (4 psi) or more for 5 seconds, indicating an under boost condition. Check tubing for restrictions, cracks and incorrect fitting connections. Check the turbocharger wastegate regulating valve solenoid for correct operation.

Possible Sources

Intake air system concern
Wastegate control hose
Turbocharger wastegate regulating solenoid (9E882 vacuum actuated)
PCM (12A650)
