Ford Escape: Brake System - General Information / General Procedures - Brake System Draining and Filling - Vehicles With: Vacuum Brake Booster
Special Tool(s) /
General Equipment
Draining
-
Refer to: Brake and Clutch Systems Health and Safety Precautions (100-00 General Information, Description and Operation).
-
Remove the brake fluid reservoir cap.
-
Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).
-
On both sides.
Remove the bleeder screw cap.
-
On both sides.
Connect the hose to bleeder screw and collect the brake fluid into the fluid container.
Use the General Equipment: Fluid Container
-
On both sides.
Loosen the bleeder screw.
Loosen:
180°
-
Apply the brake pedal several times until the brake fluid reservoir becomes empty.
-
On both sides.
Tighten the bleeder screw to specification.
Torque:
80 lb.in (9 Nm)
Filling
-
Bleed the brake system.
Refer to: Brake System Pressure Bleeding - Vehicles With: Electric
Brake Booster (206-00 Brake System - General Information, General
Procedures).
Refer to: Component Bleeding - Vehicles With: Vacuum Brake Booster
(206-00 Brake System - General Information, General Procedures).
