Ford Escape 2020-2025 Service Manual / Powertrain / Automatic Transmission / Four-Wheel Drive Systems / Removal and Installation - All-Wheel Drive (AWD) Module - 2.5L Duratec – Hybrid (121kW/164PS) (BG)

Ford Escape: Four-Wheel Drive Systems / Removal and Installation - All-Wheel Drive (AWD) Module - 2.5L Duratec – Hybrid (121kW/164PS) (BG)

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

NOTE: Removal steps in this procedure may contain installation details.

NOTE: If installing a new all-wheel drive module, it is necessary to upload the module configuration information to the scan tool prior to removing the module. This information must be downloaded into the new all-wheel drive module after installation. Using a diagnostic scan tool, begin the PMI process for the all-wheel drive module following the onscreen instructions.

  1. Remove the luggage compartment floor cover.
  1. Remove the RH loadspace storage compartment.
    1. Remove the pin-type retainers.
      Use the General Equipment: Interior Trim Remover
    1. Lift upward and remove the RH loadspace storage compartment.
    1. Release the tab from the connector.
    1. Disconnect the electrical connector from the module.
  1. Remove the nuts and the AWD module.
    Torque: 89 lb.in (10 Nm)

Installation

  1. To install, reverse the removal procedure.

NOTE: Carry out the remaining steps only if installing a new AWD module.

  1. NOTE: The 16/17 -digit alpha numeric bar code is located on the label attached to the Rear Drive Unit (RDU).

    Using the scan tool, configure RDU bar code to AWD module through the OBD port.
  1. Using a diagnostic scan tool, complete the PMI process for the AWD module following the on-screen instructions.
