Ford Escape: Battery, Mounting and Cables / Removal and Installation - Battery Cables - 1.5L EcoBoost (132kW/180PS) – I3 (Y1)

Removal

NOTE: This procedure provides information about routing, retaining points and connectors of the cable. It does not include the steps for removing components to gain access to the cable.

  1. Disconnect the battery.
    Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
    1. Torque: 133 lb.in (15 Nm)
    1. Torque: 48 lb.in (5.4 Nm)
    1. Torque: 26 lb.ft (35 Nm)
    1. Torque: 155 lb.in (17.5 Nm)
    1. Torque: 55 lb.in (6.2 Nm)
  1. NOTE: The generator electrical connector and terminals are integrated into the engine wiring harness.

    1. Torque: 155 lb.in (17.5 Nm)

Installation

  1. To install, reverse the removal procedure.
