Ford Escape: Climate Control System - General Information / Removal and Installation - Condenser Outlet Line - 1.5L EcoBoost (132kW/180PS) – I3 (Y1)
Removal
NOTICE:
During the removal of components, cap, tape or otherwise
appropriately protect all openings to prevent the ingress of dirt or
other contamination. Remove protective materials prior to installation.
NOTE:
Removal steps in this procedure may contain installation details.
-
Recover the refrigerant. Refer to the appropriate Recovery procedure in Group 412.
-
-
Remove the nut and position the A/C line aside.
Torque:
159 lb.in (18 Nm)
-
Make sure to cover any open ports to prevent debris from entering the system.
-
Remove the retainer and the condensor outlet line.
Torque:
159 lb.in (18 Nm)
Installation
-
To install, reverse the removal procedure.
-
NOTICE:
Only use the specified material to lubricate the seals.
Install and lubricate new O-ring seals. Refer to the appropriate Specifications in Group 412.
-
Lubricate the refrigerant system with the correct amount
of clean PAG oil. Refer to the appropriate Refrigerant Oil Adding
procedure in Group 412.
