Ford Escape: Engine Emission Control / Removal and Installation - Crankcase Vent Oil Separator

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Refer to: Intake Manifold (303-01B Engine - 2.0L EcoBoost (177kW/240PS) – MI4, Removal and Installation).
  1. Position aside the PCV tube.
  1. Remove the crankcase vent oil separator bolts and then remove the crankcase vent oil separator.
  1. Inspect the crankcase vent oil separator gasket.

Installation

  1. Install the crankcase vent oil separator and tighten in the sequence shown.
    Torque: 97 lb.in (11 Nm)
  1. Position back the PCV hose.
  1. Refer to: Intake Manifold (303-01B Engine - 2.0L EcoBoost (177kW/240PS) – MI4, Removal and Installation).
