Ford Escape: Handles, Locks, Latches and Entry Systems / Removal and Installation - Door Lock Cylinder

Removal

NOTE: LH (left-hand) side shown, RH (right-hand) side similar.

NOTE: Repair individual door lock cylinders by discarding the inoperative door lock cylinder and building a new door lock cylinder using the appropriate lock repair service kit. The lock repair service kit includes a detailed instruction sheet to build the new lock to match the key cut pattern for the vehicle, thus allowing for single point replacement without needing to replace or reprogram other locks or keys.

  1. Remove the exterior front door handle.
    Refer to: Exterior Front Door Handle (501-14 Handles, Locks, Latches and Entry Systems, Removal and Installation).
  1. Remove the door lock cylinder.
    1. Turn the release screw enough to release the door lock cylinder.
    1. Remove the door lock cylinder.

Installation

  1. To install, reverse the removal procedure.
  1. Rotate the key to check for correct operation.

Vehicles with passive entry

  1. If the door is equipped with one touch up/down, carry out the power door window initialization. Refer to: Power Door Window Initialization - Vehicles With: One-Touch Open and Close Front Windows (501-11 Glass, Frames and Mechanisms, General Procedures).

    General Procedures - Staged Unlock Programming

    Activation With the ignition in OFF, press the LOCK and UNLOCK buttons on the RKE transmitter simultaneously for 4 seconds. The turn signals flash twice to indicate the mode change...

    Removal and Installation - Exterior Front Door Handle

    Removal NOTE: LH (left-hand) side shown, RH (right-hand) side similar. NOTE: Removal steps in this procedure may contain installation details. Vehicles with passive entry Remove the front door window regulator and motor...

    Other information:

    Ford Escape 2020-2024 Service Manual: Diagnosis and Testing - Power Transfer Unit


    Inspection and Verification Verify the customer concern. Visually inspect for obvious signs of mechanical damage.   Visual Inspection Chart Mechanical Power transfer unit Halfshafts and CV joints Driveshaft and U-joints Wheel/tire size and brand Matching tire size and brand Tire pressure If a..

    Ford Escape 2020-2024 Service Manual: Removal and Installation - Rear Door Glass Run and Bracket


    Removal NOTE: LH (left-hand) side shown, RH (right-hand) side similar. Remove the exterior rear door handle reinforcement. Refer to: Exterior Rear Door Handle Reinforcement (501-14 Handles, Locks, Latches and Entry Systems, Removal and Installation). NOTE: This step is only necessary when installing a new component. Remove the rear door glass run and bracket. ..

    Categories

    Master Access Code

    What Is the Master Access Code

    The master access code is a factory-set five-digit entry code. You can operate the keypad with the master access code at any time. The master access code is on the owner’s wallet card in the glove box and is available from an authorized dealer.

    Displaying the Master Access Code

    To display the factory-set code in the information display:

    Ford Escape. Master Access Code

    Remove the rubber mat. Insert the first programmed key in the backup slot. Press the push button ignition switch once and wait a few seconds. Press the push button ignition switch again and remove the key. Within 10 seconds, place a second programmed intelligent access key in the backup slot and press the push button ignition switch.
