Ford Escape 2020-2024 Service Manual / Body and Paint / Body and Paint / Glass, Frames and Mechanisms / Removal and Installation - Driver Door Window Control Switch

Ford Escape: Glass, Frames and Mechanisms / Removal and Installation - Driver Door Window Control Switch

Special Tool(s) / General Equipment

Interior Trim Remover

Removal


  1. Remove the driver door window control switch and bezel as an assembly.
    1. Starting from the front, release the locking tabs from the driver door window control switch bezel assembly.
      Use the General Equipment: Interior Trim Remover
    1. Disconnect the electrical connector and remove the driver door window control switch and bezel as an assembly.
  1. NOTE: This step is only necessary when installing a new component.


    Remove the driver door window control switch.
    1. Remove the screws from driver door window control switch.
    1. Remove the driver door window control switch from the bezel assembly.

Installation

  1. To install, reverse the removal procedure.
