Ford Escape: Front Seats / Removal and Installation - Front Head Restraint Guide Sleeve
Special Tool(s) /
General Equipment
Removal
NOTE:
Driver seat shown, passenger seat similar.
-
Remove the front head restraint.
-
Depress the locking tab.
-
Remove the front head restraint.
-
Remove and discard the front head restraint guide sleeve(s).
-
Release the tab.
-
Remove and discard the front head restraint guide sleeve(s).
Use the General Equipment: Flat-Bladed Screwdriver
Installation
-
NOTICE:
Always install new head restraint guide sleeves.
Difficult adjustment of the head restraint may occur. Failure to follow
these instructions may result in component failure.
NOTICE:
The head restraint guide sleeves are not
interchangeable. Failure to install the correct head restraint guide
sleeves at the correct position may result in component failure.
Allow the head restraint guide sleeve to slide freely
through the backrest foam and backrest trim cover. Using hand pressure,
twist the head restraint guide sleeve while pushing it into the backrest
frame until the tab is locked into placed.
-
Install the front head restraint.
-
Depress the locking tab.
-
Install the front head restraint.
